| Hersteller |
ADVA Optical Networking |
| Modell |
FSP150CCF-825 |
| Produkttyp |
Carrier-Ethernet Service Demarcation / Service Extension |
| Zugangs-/Client-Ports |
4 × 10/100 Base-T + 1 × 10/100/1000 Base-T oder optional 100/1000 Base-X (SFP) |
| Netzwerk-Ports (Uplink) |
2 × 100/1000 Base-T oder 100/1000 Base-X (SFP) |
| Interface-Redundanz |
Link Aggregation (LAG) – Active / Standby |
| VLAN-Support |
4 096 VLANs (802.1Q), Q-in-Q (Service-provider tagging), 2-Tag Handling (Push/Pop/Swap), IEEE 802.1ad Provider-Bridging, Ethertype-Translation |
| Traffic Management |
802.1p, 802.1Q, IP-TOS/DSCP classify; MEF-konformes Policing (CIR/CBS/EIR/EBS), 3-Color Marking, 8 CoS-Klassen, Hierarchical Queuing, Port Shaping |
| Ethernet-OAM / SLA-Monitoring |
802.3ah EFM-OAM, 802.1ag CFM, Y.1731 Performance Monitoring, Loopbacks, Cable Diagnostics, RFC 2544 Test Generator/Analyzer, UDP/ICMP Echo SLA, ESA Timestamp, Link Loss Forwarding, „Dying Gasp“ Alarm |
| Performance Monitoring |
Per-Port/Per-Service RMON-Etherstats (RFC 2819), 15-min / 1-Tages-Binning, PHY-Monitoring (802.3ah/G.8021), Y.1731 Frame-Loss, Multi-CoS, Alarme, SFP physikalische Parameter, Temperatur-Überwachung |
| Provisionierung |
Zero-Touch Provisioning, DHCP/BOOTP, 802.1x Port Auth, TFTP, Text Configs |
| Service-Intelligence Features |
MEF-zertifizierte UNI-Implementierung, hierarchisches QoS/Shaping, SLA-Verifikation, Low-Touch Install |
| Einsatzbereich |
Carrier-Ethernet Demarcation – E-Line, E-LAN, E-Tree Services |
